Smart Hardware & Security Surveillance_RL010B-RBA
- 13.2Ah High Capacity
- 92.16Wh Long-Lasting Power
- 5A Stable Output
- 5A Fast Charging
The battery uses a CC/CV (Constant Current/Constant Voltage) charging profile, with a standard charging current of 2.56A and a maximum charging current of up to 5A. The standard discharge current is 2.56A, with a maximum discharge current of 5A, providing reliable power for high-definition surveillance, wireless data transmission, and the simultaneous operation of multiple modules.With its high capacity and stable power output, the battery is well suited for portable and mobile security surveillance equipment requiring extended standby time and continuous operation.
Product Specifications & Configuration| No. | Item | Parameter | Remarks | |
| 1 | Capacity | Typ. 13200mAh | 0.2C Discharge | |
| Min. 12800mAh | ||||
| 2 | Rated Energy | 92.16Wh | ||
| 3 | Nominal Voltage | 7.2V | ||
| 4 | Charge Voltage Limit | 8.4V | ||
| 5 | Maximum Charging Voltage | 8.43V | ||
| 6 | Discharge Termination Voltage | 5.6V | ||
| 7 | Discharge Cut-off Voltage | 5V | ||
| 8 | Charging Mode | CC-CV | CC/CV | |
| 9 | Charging Current | 2560 mA | ||
| 5000 mA | ||||
| 10 | Standard Discharge Current | 2560 mA | 0.2C | |
| 11 | Maximum Discharge Current | 5000 mA | ||
| 12 | Operating Temperature | Charging | 0°C~+15°C | 3.3A Max Charging to 8.4V |
| 15°C~+45°C | 5A Max Charging to 8.4V | |||
| 45°C~+60°C | 5A Max Charging to 8.3V | |||
| Discharging | -20°C~+60°C | 5A Max Discharging to 5.6V | ||
| 13 | Storage Temperature | Less than 1 Month | -20°C~+50°C | Capacity Recovery Rate > 80% |
| Less than 3 Months | -20°C~+40°C | |||
| Less than 1 Year | -20°C~+20°C | |||
| 14 | Storage Requirement | Recharge the battery every 4 months during storage. | ||
| 15 | Relative Humidity | 65±20% | ||
| 16 | Battery Internal Resistance | ≤ 130mΩ | Measure the battery AC internal resistance at 1 kHz after standard charging. | |
| 17 | Battery Weight | 565g | About | |
| 18 | Battery Dimensions | Length | MAX84.60mm | |
| Width | MAX62.60mm | |||
| Thickness | MAX92.0mm | |||
13.2Ah High Capacity & Long Runtime: 7.2V / 13.2Ah, with a rated energy of 92.16Wh, providing long-lasting continuous power for monitoring, communication, and sensing systems
5A Stable Power Output: Maximum discharge current up to 5A, meeting the power demands of cameras, image processing, wireless communication, and other multi-module operations
5A Fast Charging: Supports a maximum charging current of 5A, improving charging efficiency and reducing equipment downtime
Stable & Safe Power Supply: Adopts CC/CV charging management with defined charging upper limits, discharge termination, and discharge cutoff voltage to enhance battery stability and operational safety
