Robotic Battery & Custom Robotic Battery Pack

Lightweight Power Lithium Battery Packs

Gushine lightweight power solution integrates advanced battery management functions, offering high precision, low power consumption, and multiple safety protections to ensure stable operation and long battery life. Features include:

Real-time battery monitoring and balancing to extend battery lifespan.
Built-in multi-temperature protection points and over-discharge prevention.
Supports RTC data logging, using URAT, CAN, RS485 communication to ensure stable transmission.
Dynamic pressure differential detection and adjustable protection parameters to enhance safety.
Excellent high-temperature storage capabilities, customizable waterproof ratings, suitable for various application environments.

Custom Lithium Battery Pack

Dwonload:

Industry Applications

Underwater Cleaning Robot

Lightweight Power Battery Solution

Cylindrical Battery Module

18650/4S4P

Waterproof Venting Film

Balances internal and external pressure

NTC Sensor

Temperature monitoring, over-temperature protection, fault diagnosis, optimizing charging and discharging process

BMS

Intelligent supervision, fault alarm

Potting

Enhances waterproof performance and internal insulation, improves heat dissipation

Featured Models

10.8V 2600mAh Robot vacuums lithium battery pack

Model: BL006B-RBA-3S1P
Rated Capacity: 2600mAh
Nominal Voltage: 10.8V
Dimensions: 134.0(L) x 38.0(W) x 20.5(T) mm
Application: Robot vacuums

14.8V 10400mAh Underwater robotics lithium battery pack

Model: BA001B-LS-4S4P
Rated Capacity: 10400mAh
Nominal Voltage: 14.8V
Dimensions: 159.16(L) x 72.4(W) x 68.9(T) mm / 1030g
Features: BMS, deep-water waterproof (30m/2 hours), power battery
Application: Underwater robotics

25.55V 7500mAh Wireless pool cleaning robot lithium battery pack (7S3P)

Model: FY001B-RBA-7S3P
Rated Capacity: 7500mAh
Nominal Voltage: 25.55V
Dimensions: 218.2(L) x 103.2(W) x 76.3(T) mm
Features: BMS, deep-water waterproof (6m/24 hours), waterproof connector
Application: Pool cleaning robots

Solution Overview

Featured Batteries

Items	Details
Battery Cell	18650/21700, Lipo battery cells, Prismatic cells
Configuration	4S-17S
Capacity	2000mAh-50000mAh
Temperature	Charge: 0℃ to 45℃ Discharge: -20℃ to 60℃
Protection	Shock-resistant, waterproof,
Software/Hardware	BMS, intelligent control module, smart monitoring, temperature monitoring, communication (CAN, RS485, URAT) and data management, fault diagnosis, and protection.

Premium cells

Battery packs using high quality cells from LG, Samsung, Panasonic and other top tier manufacturers.

Dust-proof and waterproof

IP67, IP 68 rated, ensuring safe operation in hazardous environment.

Real-time Communication

I²C communication function, ensuring seamless and reliable data transmission.

Videos

Ultrasonic Welding for No Water Ingress-封面.jpg

Gushine Battery Waterproofing：Ultrasonic Welding for No Water Ingress

Gushine Waterproof Li-ion Battery PACK | IP67/IP68 Rated

Gushine Waterproof Lithium Battery Test – 30 Minutes Underwater
