Custom Battery Chargers

Home / Services / Custom Battery Chargers / Custom Battery Chargers

Custom Battery Charger Solutions

We offer customized charging solutions using advanced DC-DC technology with dynamic charging adjustments, optimized for each battery’s chemistry and charging needs. Our smart chargers communicate with battery packs in real-time, enhancing safety, lifespan, and charging management. Perfect for industrial devices, handheld terminals, smart homes, robotics, drones, medical devices, and more.

Smart Charger (or Charging Dock) Features:

Multi-Interface Support: Type-C, DC, Micro-USB, and more.
Adjustable Settings: Customizable voltage, current, charging mode, and temperature protection.
Real-Time Display: Battery indicators and LCD charging progress.
Protection Mechanisms: Overcharge, overcurrent, and temperature protection.
Smart Management: Optimizes charging based on real-time battery status.

Custom Multi-interface Input

Real-time Status Display

Multiple Safety Protections

Smart Charging Management

Key features

Modular Design

Single chargers can be combined into a multi-unit dock
for simultaneous charging of multiple battery packs

Multi-Interface Supported

Such as Type-C, DC, Micro-USB, etc.

Adjustable Settings

Customizable voltage, current, charging mode, and temperature protection

Protection Mechanisms

Overcharge, overcurrent, and temperature protection

Smart Management

Optimizes charging based on real-time battery status

Real-Time Display

Battery indicators and LCD charging progress

Highly Customized

Custom charging docks to fit the size, performance, and environment of the end product or battery module

Service Process

Requirement Analysis

Technical Solution Evaluation

Preliminary Solution & Quotation

Solution Approval, Sample Request

Product Design

Sample Production & Testing

Sample Approval

Product Certification

Trial Production

Mass Production & Delivery

Products Case

Two-Way Radio Desktop Charger MZ831C (8.3V/1A)

Model: MZ831C
Input Voltage: DC 12V ± 5% (11.4V - 12.6V)
Input Current: 1000mA
Charging Voltage: 8.3V
Charging Current: 1000mA ± 100mA
CC Constant Current: 1000mA
CV Constant Voltage: 8.3V
Operating Temperature: -10℃ to 40℃
Indicator: Red light (charging); Green light (fully charged); Standby (Green light on)
Dimensions: 79.30 * 78.04 * 46.30 mm

Handheld Terminal Desktop Charger MZ960C (4.35V/2A)

Model: MZ960C
Input Voltage/Current: DC 9V / 4A
Output Voltage/Current: 9V (Main Unit) / 4.35V (Battery)
Output: 2A (Main Unit) / 2A (Battery)
Dimensions: 118 * 87 * 50 mm
Features: Overvoltage, overcurrent, and short-circuit protection

Two-Way Radio Charging Dock DF005C-RXB (10V / 2.5A)

Model: DF005C-RXB
Input Voltage / Current: DC 10V-15V / 2.5A
Battery Output: 8.4V ± 0.05V / 1000mA ± 100mA
Device Output: 8.4V ± 0.05V / 1000mA ± 100mA
Charging Temperature: 50℃ ± 3℃ (MAX) / 0℃ ± 3℃ (MIN)
Operating Temperature: -10℃ to 55℃
Indicator: Red light (charging); Orange light (battery at 90%); Green light (fully charged); Red light flashing (charging error)

Two-Way Radio 4-Bay Charger AK810-C4 (12V / 1A)

Model: AK810-C4
Input Voltage / Current: DC 12V ± 5% / 1000mA
Charging Voltage / Current: 8.3V / 1000mA
CC Constant Current / Constant Voltage: 1000mA / 8.3V
Operating Temperature: -10℃ to 40℃
Charging Indicator: Red light (charging); Green light (fully charged); Standby (Green light on)
Dimensions: 365.3 * 143.7 * 64.7 mm

Partner With

Application Scenarios

Industrial Handheld Terminals

Smart Hardware

Lightweight Power

Healthcare & Medical

Inquiry Form

Choose Gushine for professional, reliable, and high-quality custom lithium battery solutions. Contact us today to get started on your custom battery project!
